The FF900R17ME7-B11 features TRENCHSTOP™ IGBT7 7th generation emitter control diodes, NTC, PressFIT crimp technology, and can also be pre-coated with Thermal Interface Material (TIM).The FF900R17ME7-B11 features the highest power density, outstanding VCE,sat, Tvj op = 175°C at overload, optimised switching losses, enhanced dv/dt controllability, improved diode softness and Erec losses, enhanced tolerance to cosmic rays, improved terminations, crimp-on drive pins and screw-on power terminals, integrated NTC temperature sensors in the module, insulated substrate, designed with moulded terminals for compactness and reliability, higher inverter output current with no change in form factor, avoiding the need to Parallel connection of IGBT modules simplifies the inverter system, thus reducing system cost, easy to assemble and extremely reliable.

Product Attributes

IGBT Type: Trench Field Cutoff

Configuration: 2 independent

Voltage - Collector Breakdown (max): 1700 V

Current - Collector (Ic) (max): 900 A

Power - Max: 20 mW

Vce(on) at varying Vge, Ic (max): 1.85V @ 15V, 900A

Current - Collector Cutoff (max): 5 mA

Input capacitance (Cies) at varying Vce: 93.8 nF @ 25 V

Input: Standard

NTC Thermistor: Yes

Operating Temperature: -40°C ~ 175°C (TJ)

Mounting Type: Chassis Mount

Package/Housing: Module

Applications

• High power converters

• Medium Voltage Converters

• Motor drives

• Wind turbines
