The STGE200NB60S STMicroelectronics has designed an advanced family of IGBTs using the latest high-voltage technology based on a patented ribbon layout, the PowerMESH™ IGBT family performance. The suffix "S" stands for the fact that the series is optimised for very low VCE(sat).The STGE200NB60S features high input impedance (voltage driven), low on-state voltage drop (Vcesat), turn-off losses including tail current, low gate charge, and high current capability.

Product Attributes

IGBT Type: -

Configuration: Single

Voltage - Collector Breakdown (Max): 600 V

Current - Collector (Ic) (max): 200 A

Power - Max: 600 W

Vce(on) (max) at different Vge, Ic: 1.6V @ 15V, 100A

Current - Collector Cutoff (max): 500 µA

Input capacitance (Cies) at varying Vce: 1.56 nF @ 25 V

Input: Standard

NTC Thermistor: None

Operating Temperature: -55°C ~ 150°C (TJ)

Mounting Type: Chassis Mount

Package/Housing: SOT-227-4, miniBLOC

Supplier Device Package: ISOTOP

Applications

• Low frequency motor controllers

• Aluminium welding equipment
