The AMC23C10QDWVRQ1 is a precision, short-response-time isolated comparator. This device is specifically designed for zero-crossing detection of high-voltage signals, achieving electrical isolation between such signals and low-voltage circuits. The open-drain and push-pull outputs are separated from the input circuitry by an isolation barrier offering exceptional immunity to electromagnetic interference. Certified to VDE 0884-17 and UL1577 standards, this isolation barrier provides enhanced electrical isolation rated up to 5kVRMS. It also supports operating voltages up to 1kVRMS.

AMC23C10QDWVRQ1 Product Features:

High-side power supply with wide voltage range: 3V to 27V

Low-side power supply voltage range: 2.7V to 5.5V

Flip-flop threshold error: ±6mV (maximum)

Open-drain and push-pull outputs

Propagation delay: 230ns (typical)

High CMTI:

Open-drain output: 75V/ns (minimum)

Tranquilised output: 100 V/ns (minimum)

AMC23C10QDWVRQ1 Applications:

Zero-crossing detection and general monitoring in the following applications:

– Solid-state relays (SSR)

– Hybrid, electric and powertrain systems

– Battery management systems

– On-board chargers
