SPC5604BF2MLQ6 is a high-performance 32-bit automotive-grade microcontroller based on the Power Architecture® e200z4 core, operating at up to 100 MHz. This chip utilises an LQFP-144 package and is specifically designed for automotive electronics applications, meeting the stringent demands of modern automotive systems for performance, reliability, and functional safety.

SPC5604BF2MLQ6 Product Features

High-performance processing capability: Supports real-time control and complex algorithm processing.

Extensive peripheral interfaces: Integrates multiple flexible timer modules and supports diverse communication protocols.

High reliability: Complies with the automotive electronics industry's highest standards, meeting stringent reliability and safety requirements.

Low-power design: Optimised energy efficiency for automotive applications.

Development tool support: Comprehensive development toolchain including compilers, debuggers, and simulators.

SPC5604BF2MLQ6 Product Specifications

Manufacturer: NXP

Product Type: 32-bit Microcontroller - MCU

Series: MPC560xB

Mounting Style:    SMD/SMT

Package / Case:    LQFP-144

Core:    e200z0

Program Memory Size:    512 kB

Data RAM Size:    64 kB

Data Bus Width:    32 bit

ADC Resolution:    10 bit

Maximum Clock Frequency:    64 MHz

Number of Input/Output Pins:    123 I/O

Supply Voltage - Minimum:    3 V

Supply Voltage - Maximum:    5.5 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Qualification:    AEC-Q100

Data RAM Type:    SRAM

Data ROM Type:    EEPROM

Interface types:    CAN, I2C, LIN, SPI

Humidity sensitivity:    Yes

Number of ADC channels:    36 Channel

Number of timers/counters:    1 x 16 bit

Operating supply voltage:    3 V, 5 V

Processor family:    SPC5604

SPC5604BF2MLQ6 Application Scenarios

The SPC5604BF2MLQ6 finds extensive application across various control systems within the automotive industry, such as:

Body Control Modules (BCM): Managing functions including lighting, door locks, and air conditioning.

Chassis Systems: Such as brake control and suspension adjustment.

Powertrain Control Units (PCU): Employed for engine management and transmission coordination.

Advanced Driver Assistance Systems (ADAS): Including blind spot monitoring and lane departure warning.
