S9S12G64AMLF is a 16-bit microcontroller (MCU) belonging to the S12G series. Based on the S12 core architecture with a maximum operating frequency of 25 MHz, this microcontroller is suitable for a wide range of embedded applications, including automotive-grade applications.

S9S12G64AMLF Product Specifications

Manufacturer:    NXP

Product Type:    16-bit Microcontroller - MCU

Core:    S12

Program Memory Size:    64 kB

Data RAM Size:    4 kB

Package / Case:    LQFP-48

Maximum Clock Frequency:    25 MHz

ADC Resolution:    10 bit

Number of Input/Output Pins:    40 I/O

Supply Voltage - Min:    3.15 V

Supply Voltage - Max:    5.5 V

Mounting Style:    SMD/SMT

Data Bus Width:    16 bit

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    S12G

Analogue Supply Voltage:    3.13 V to 5.5 V

S9S12G64AMLF Product Features

High-precision ADC: 10-bit resolution, 12 channels.

Extensive I/O interfaces: 40 I/O ports supporting multiple communication protocols.

Low-power design: Operating supply voltage range from 3.13 V to 5.5 V.

High reliability: Operating temperature range from -40°C to +125°C.

Compact packaging: LQFP-48 package, saving PCB space.

On-chip memory: 64 KB Flash program memory, 4 KB RAM, 2 KB EEPROM.

Watchdog timer: Integrated watchdog timer for enhanced system stability.

Application Scenarios

The S9S12G64AMLF is suitable for diverse applications requiring high-precision ADCs and extensive I/O interfaces, including but not limited to:

Automotive electronics: Automotive-grade applications such as engine control and body electronics.

Industrial automation: Control and monitoring of industrial equipment.

Medical devices: Applications demanding high-precision data acquisition.

Consumer electronics: Smart home appliances, portable devices, and similar applications.
