The UJA1169ATK is a miniature high-speed CAN System Base Chip (SBC) incorporating an HS-CAN transceiver compliant with ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 standards, including CAN FD up to 5 Mbit/s and an integrated 5 V or 3.3 V 250 mA power supply. It further incorporates a watchdog timer, a serial peripheral interface (SPI), and LIMP output.

UJA1169ATK Product Attributes

Type:    High-Speed CAN SBC (System Building Block)

Mounting Style:    SMD/SMT

Package / Case:    HVSON-20

Data Rate:    5 Mb/s

Number of Drivers:    1 Driver

Number of Receivers:    1 Receiver

Supply Voltage - Min:    2.8 V

Supply Voltage - Maximum:    28 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +150°C

Operating Supply Current:    46 mA

ESD Protection:    8 kV

Qualification:    AEC-Q100

Operating Supply Voltage:    2.8 V to 28 V

UJA1169ATK Product Applications

Industrial Control

Forward-View Camera

Automotive Electronics

Central Stack Module

Mid-Range Body Control Computer

Transmission Control

Sunroof Control Module

Seat Control Module

Steering Wheel Control Switch

Temperature Control Module

Electronic Steering Column Module

Matrix Front Lighting Control

Tyre Pressure Monitoring System (TPMS)
