MMA8451QR1 is a smart, low-power, three-axis, capacitive, micromachined accelerometer with 14 bits of resolution. This accelerometer is packed with embedded functions with flexible user programmable options, configurable to two interrupt pins. Embedded interrupt functions allow for overall power savings relieving the host processor from continuously polling data.

Specifications Of MMA8451QR1

Type:Digital

Axis:X, Y, Z

Acceleration Range:±2g, 4g, 8g

Sensitivity (LSB/g):4096 (±2g) ~ 1024 (±8g)

Bandwidth:0.78Hz ~ 400Hz

Output Type:I2C

Voltage - Supply:1.95V ~ 3.6V

Features:Adjustable Bandwidth, Selectable Scale, Sleep Mode

Operating Temperature:-40°C ~ 85°C

Features Of MMA8451QR1

• 1.95 V to 3.6 V supply voltage

• 1.6 V to 3.6 V interface voltage

• ±2 g/±4 g/±8 g dynamically selectable full scale

• Output data rates (ODR) from 1.56 Hz to 800 Hz

• 99 μg/√Hz noise

• 14-bit and 8-bit digital output

• I2C digital output interface

• Two programmable interrupt pins for seven interrupt sources

• Three embedded channels of motion detection

— Freefall or motion detection: one channel

— Pulse detection: one channel

— Jolt detection: one channel

• Orientation (portrait/landscape) detection with programmable hysteresis

• Automatic ODR change for auto-wake and return to sleep

• 32-sample FIFO

• High-pass filter data available per sample and through the FIFO

• Self-test

• Current consumption: 6 μA to 165 μA

Applications Of MMA8451QR1

• E-compass applications

• Static orientation detection (portrait/landscape, up/down, left/right, back/front position identification)

• Notebook, e-reader, and laptop tumble and freefall detection

• Real-time orientation detection (virtual reality and gaming 3D user position feedback)

• Real-time activity analysis (pedometer step counting, freefall drop detection for HDD, dead-reckoning GPS backup)

• Motion detection for portable product power saving (auto-sleep and auto wake for cell phone, PDA, GPS, gaming)

• Shock and vibration monitoring (mechatronic compensation, shipping and warranty usage logging)

• User interface (menu scrolling by orientation change, tap detection for button replacement)
