The LTM4605IV is a high-efficiency switch-mode buck-boost power supply. The package includes a switch controller, power FET, and supporting components. The LTM4605IV operates over an input voltage range of 4.5V to 20V and supports an output voltage range of 0.8V to 16V (set by a single resistor). Fault protection features include overvoltage and foldback current protection. This DC/DC μModule® is housed in a compact, thermally enhanced 15mm x 15mm x 2.8mm LGA package.

Product Details:

Model: LTM4605IV

Package: LGA-141

Type: μModule buck-boost regulator

Description: High-efficiency, buck-boost DC/DC μModule regulator

LTM4605IV Product Attributes:

Series: µModule®

Type: Non-isolated PoL module

Number of outputs: 1

Voltage - Input (minimum): 4.5V

Voltage - Input (maximum): 20V

Voltage - Output 1: 0.8 to 16V

Current - Output (Maximum): 5A

Operating Temperature: -40°C to 85°C

Efficiency: 98%

Mounting Type: Surface Mount

Package/Case: 141-BLGA Module

Size/Dimensions: 0.59‘ L x 0.59’ W x 0.11" H (15.0mm x 15.0mm x 2.8mm)

Supplier Device Package: 141-LGA (15x15)

LTM4605IV Applications:

Telecom, servers, and network equipment

Industrial and automotive equipment

High-power battery-powered devices
