The LTM4607IV is a high-efficiency switch-mode buck-boost power supply. The package includes a switch controller, power FET, and supporting components. The LTM4607IV operates over an input voltage range of 4.5V to 36V and supports an output voltage range of 0.8V to 24V (set by a single resistor).

Product Details:

Model: LTM4607IV

Package: LGA-141

Type: μModule Buck-Boost Regulator

Description: 36VIN, 24VOUT, high-efficiency, buck-boost DC/DC μModule regulator (power module)

LTM4607IV Product Attributes:

Series: µModule®

Type: Non-isolated PoL module

Number of outputs: 1

Voltage - Input (minimum): 4.5V

Voltage - Input (maximum): 36V

Voltage - Output 1: 0.8 ~ 24V

Current - Output (maximum): 5A

Application: ITE (commercial)

Operating temperature: -40°C ~ 85°C

Efficiency: 98%

Mounting Type: Surface Mount

Package/Case: 141-BLGA Module

Size/Dimensions: 0.59‘ L x 0.59’ W x 0.11" H (15.0mm x 15.0mm x 2.8mm)

Supplier Device Package: 141-LGA (15x15)

LTM4607IV Product Features:

Single inductor architecture allows VIN to be higher, lower, or equal to VOUT

Wide VIN range: 4.5V to 36V

Wide VOUT range: 0.8V to 24V

5A DC (10A DC in buck mode)

High efficiency: up to 98%

Current-mode control

Power-good output signal

Lockable fixed frequency: 200kHz to 400kHz

Ultra-fast transient response

Current foldback protection

Output overvoltage protection

Small, flat surface-mount LGA package (15mm x 15mm x 2.8mm)
