ADN4694EBRZ is a multi-point low-voltage differential signaling (M-LVDS) transceiver (driver and receiver pair) with a maximum operating speed of 100 Mbps (50 MHz). Actual pressure swing rate control at the output end of the driver. The receiver can detect bus status using differential inputs as low as 50 mV within a common mode voltage range of -1 V to+3.4 V. ESD protection up to ± 15 kV is provided on the bus pins.

Features

Multi point LVDS transceiver (low-voltage differential signal driver and receiver pair)

Switching speed: 100 Mbps (50 MHz)

Supported bus load: 30 ohms to 55 ohms

Two types of receivers are available for selection

Class 2 (ADN4694E/ADN4695E): 100 mV threshold offset, providing open circuit and bus idle fault safety functions

Compliant with the TIA/EIA-899 standard of M-LVDS

Burrless power on/off on M-LVDS bus

Driver output conversion time is controllable

Common mode range: -1 V to+3.4 V, allowing communication under 2 V ground noise

Product Attributes - ADN4694EBRZ

Product type: LVDS interface integrated circuit

Type: High Speed M-LVDS Transceiver

Number of exciters: 1 Driver

Number of receivers: 1 Receiver

Data rate: 100 Mb/s

Input type: LVDS

Power Supply Voltage - Maximum: 3.6 V

Power Supply Voltage - Minimum: 3 V

Minimum operating temperature: -40 ° C

Maximum operating temperature:+85 ° C

Installation style: SMD/SMT

Packaging/Box: SOIC-8

ESD protection: With ESD protection

Encapsulation: Tube

Height: 1.75 mm

Input voltage - maximum value: 2 V

Input voltage - minimum value: 800 mV

Length: 5mm

Maximum output voltage: 650 mV

Working power supply current: 16 mA

Working power supply voltage: 3.3 V

Pd power dissipation: 94 mW

Application - ADN4694EBRZ

-Backplane and cable multi-point data transmission

-Multi point clock allocation

-Low power consumption and high-speed alternative devices can shorten the RS-485 link

-Networking and wireless base station infrastructure
