The Microchip LAN9500AI-ABZJ high-speed USB 2.0 to 10/100 Ethernet controller offers a high-performance, cost-competitive USB-to-Ethernet connectivity solution, integrating a 10/100 Ethernet PHY, high-speed USB 2.0 PHY, high-speed USB 2.0 controller, 10/100 Ethernet MAC, TAP controller, EEPROM controller, and FIFO controller, all packaged in a compact 56-pin QFN package.

The LAN9500AI-ABZJ supports ±8kV HBM and ±15kV air discharge electrostatic discharge (ESD) protection, requiring only a single 25MHz crystal oscillator, helping to minimise the bill of materials (BOM) cost for external components. External MII and Turbo MII interfaces support Fast Ethernet, HomePlug®, and HomePNA™ (HPNA) functionality.

LAN9500AI-ABZJ Features

Single-chip, high-speed USB 2.0 to 10/100 Ethernet controller

±8kV HBM and ±15kV air discharge electrostatic discharge (ESD) protection

Requires only a single 25MHz crystal

No EEPROM design option helps reduce bill of materials cost

Supports low-power operating modes such as enhanced power detection shutdown

Supports multiple power management features, including Wake-On LAN, Magic Packet™, and link status change detection

External MII and Turbo MII (supporting up to 200Mbps rates)

LAN9500A uses Microchip's proprietary NetDetach™ technology to reduce hardware power consumption

LAN9500 and LAN9500A are compatible

8x8mm, 56-pin QFN package, suitable for compact designs

Industrial temperature range options available

LAN9500AI-ABZJ Technical Specifications

Product: USB Controller

Type: Bridge, USB to Ethernet

Mounting Style: SMD/SMT

Package/Enclosure: QFN-56

Standard: USB 2.0

Power Supply Voltage - Minimum: 3.3 V

Power Supply Voltage - Maximum: 3.3 V

Minimum Operating Temperature: -40°C

Maximum Operating Temperature: +85°C

Humidity Sensitivity: Yes

Operating Power Supply Voltage: 3.3 V

LAN9500AI-ABZJ Application Areas

PC Docks

Netbooks and Ultra-Mobile Personal Computers (UMPC)

Mobile Internet Devices (MID)

Digital TVs/Video Recorders/Set-Top Boxes

Network Printers

Game Consoles

Stand-alone USB-to-Ethernet Adapters

Embedded Systems

Industrial Applications
