The USB2514B-I/M2 is a low-power, configurable 4-port USB 2.0 high-speed hub controller from Microchip, designed for embedded USB solutions. It supports low-speed, full-speed, and high-speed downstream devices, finding extensive application in industrial equipment, embedded systems, and consumer electronics.

Specifications

Package: SQFN-36

Core Function: 4-port USB 2.0 high-speed hub controller

Protocol Support: USB 2.0 (High-Speed - 480 Mbps, Full-Speed - 12 Mbps, Low-Speed - 1.5 Mbps)

Supply Voltage: 3.0V to 3.6V

Typical Operating Current: 70 mA

Data Transfer Rate: 480 Mbps

Operating Temperature: -40°C to +85°C (Industrial Grade)

Interface Types: USB 2.0, I2C, SMBus

Number of Ports: 4 downstream ports

Battery Charging Support: Compliant with USB Battery Charging Specification Revision 1.1 (CDP)

ESD Protection: 4 kV HBM (JESD22-A114F)

USB2514B-I/M2 Features

High Performance: Utilises MultiTRAK technology with dedicated transaction converters per port for efficient data transfer.

High Compatibility: Fully compliant with USB 2.0 specifications, enabling seamless connectivity with most USB devices on the market.

High Customisation: Enhanced OEM configuration flexibility via I²C EEPROM or SMBus slave port.

Power Management Capabilities: Enables individual or combined power control for each downstream port, supporting self-powered or bus-powered operation.

High Integration: Fully integrates USB termination and pull-up/pull-down resistors, reducing external component requirements.

Robust Protection Mechanisms: Incorporates 4kV HBM JESD22-A114F ESD protection, enhancing device reliability and stability.
