The LTC2052HVIS is a four-channel zero-drift operational amplifier housed in a 14-SOIC (wide-body) package. The LTC2052HVIS operates on a single 2.7V supply and supports ±5V applications. Current consumption is 750μA per operational amplifier.

Despite its compact size, the LTC2052HVIS delivers exceptional DC performance. Typical input offset voltage and offset drift are 0.5μV and 10nV/℃, respectively. With a power supply rejection ratio (PSRR) and common-mode rejection ratio (CMRR) exceeding 130dB, it provides support for near-zero DC offset and drift.

The input common-mode voltage range extends from the negative power supply to up to 1V above the positive power supply (typical). The LTC2052HVIS also features an enhanced output stage capable of driving loads as low as 2kΩ to both positive and negative power rails. The open-loop gain is typically 140dB. Additionally, the LTC2052HVIS offers 1.5μVP-P DC-to-10Hz noise and a 3MHz gain-bandwidth product.

LTC2052HVIS Features

Maximum offset voltage: 3μV

Maximum offset voltage drift: 30nV/°C

Small footprint, flat MS8/GN16 package

Single-supply operation: 2.7V to ±5.5V

Noise: 1.5µVP-P (typical value over the 0.01Hz to 10Hz frequency range)

Voltage gain: 140 dB (typical)

PSRR: 130 dB (typical)

CMRR: 130 dB (typical)

Supply current: 0.75 mA per amplifier (typical)

Extended common-mode input range

Rail-to-rail output swing

Operating temperature range: –40°C to 125°C

LTC2052HVIS Applications

Thermocouple amplifiers

Electronic scales

Medical instruments

Strain gauge amplifiers

High-resolution data acquisition

High DC accuracy RC active filters

Low-side current sensing
