The ADA4522-1ARMZ single-channel, zero-drift, operational amplifier is optimised for total accuracy over time, temperature and voltage conditions. The ADA4522-1 op-amp provides low noise and power consumption, ground sensing inputs, and rail-to-rail outputs. The ADA4522-1 is guaranteed rated at 5.0V, 30V, and 55V supply voltages and can operate over the 4.5V to 55V range. On-chip filtering provides high immunity to electromagnetic interference (EMI). The operational amplifiers' wide operating voltage and temperature range, high open-loop gain, and very low DC and AC errors make them ideal for amplifying very small input signals. These features also allow these devices to accurately replicate large signals in a wide range of applications.

Product Attributes

Amplifier Type: Zero Drift

Number of circuits: 1

Output Type: Full Swing

Slew rate: 1.7 V/µs

Gain Bandwidth Product: 2.7 MHz

Current - Input Bias: 50 pA

Voltage - Input Compensation: 1.5 µV

Current - Supply: 830µA

Current - Output/Channel: 32 mA

Voltage - Span (Min): 4.5 V

Voltage - Span (Max): 55 V

Operating Temperature: -40°C ~ 125°C

Mounting Type: Surface Mount

Package/Shell: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

Supplier Device Package: 8-MSOP

Applications

Inductance, capacitance and resistance (LCR) meters/megohmmeter front-end amplifiers

Load cells and bridge sensors

Magnetic balances

High Precision Shunt Detection

Thermocouple/Resistance Temperature Detector (RTD) sensors

Programmable Logic Controller (PLC) Input and Output Amplifiers
