The AD9251BCPZ-20 is a single-chip, dual-channel, 14-bit, 20 MSPS analog-to-digital converter (ADC) powered by a 1.8V supply, featuring an integrated high-performance sample-and-hold circuit and an on-chip reference voltage source. The following are its main features:

Powered by a 1.8V analog power supply

Output power supply from 1.8V to 3.3V

SNR

74.3 dBFS (9.7 MHz input)

71.5 dBFS (200 MHz input)

Spurious dynamic range (SFDR)

93 dBc (9.7 MHz input)

80 dBc (200 MHz input)

Low power consumption

Each channel is 33 mW (20 MSPS)

Each channel is 73 mW (80 MSPS)

Differential input, 700 MHz bandwidth

2 V p-p differential analog input

On-chip reference voltage source and sample-and-hold circuit

DNL = ±0.45 LSB

Serial port control options

Offset binary, Gray code or binary complement data formats

Optional clock duty cycle stabilizer

1 to 8 integer input clock divider

Data output reuse option

Built-in optional digital test code generation function

Energy-saving shutdown mode

Data clock output with programmable clock and data alignment functions

The AD9251BCPZ-20 is packaged in a 64-pin LFCSP package, complies with RoHS standards, and has a rated temperature range of -40 °C to +85°C within the industrial temperature range.

Application field

Communications ‌ : wireless signal acquisition and modulation/demodulation

Industrial control ‌ : real-time processing of sensor data

Medical imaging ‌ : data conversion of ultrasound /MRI equipment
