The AD9268BCPZ-125 is a dual-channel, 16-bit analog-to-digital converter (ADC) that supports a 125 MSPS sampling rate and adopts a differential pipeline architecture design. It is specifically designed for high-performance communication applications. This product integrates a reference voltage source to simplify the design. Duty cycle stabilizers can be used to compensate for the fluctuations in the duty cycle of the ADC clock, enabling the converter to maintain excellent performance.

Technical parameters

Number of digits: 16

Sampling rate (per second) : 125 meters

Input number: 2

Input type: Difference

Data interface: LVDS - Parallel, parallel

Configuration: S/H-ADC

Ratio -S /H:ADC: -

A/D converter number: 2

Architecture: Pipeline

Reference types: external, internal

Voltage - Power supply, analog: 1.7V to 1.9V

Voltage - power supply, number: 1.7V to 1.9V

Feature: Synchronous sampling

Operating temperature: -40°C to 85°C

Packaging/Housing: 64-LFCSP

Application scenarios

The AD9268BCPZ-125 is widely used in the following scenarios:

Communication

Diversity radio system

Multimode digital Receiver (3G

GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA

I/Q demodulation system

Intelligent antenna system

General Software-defined Radio

Broadband Data application

Ultrasonic equipment
