The AD737JRZ is a low-power, precision true root mean square (RMS) to direct current (DC) converter in an SOIC-8 package, designed for high-precision signal measurement. The device accurately calculates the true RMS, average rectified value, or absolute value of AC or DC input signals, making it suitable for applications such as test instruments, industrial control, audio processing, and portable devices.

AD737JRZ Features

Calculation

True RMS

Average rectified value

Absolute value

200 mV full-scale input range (larger input range when using an input attenuator)

Direct interface with 3½-digit CMOS ADC

High input impedance: 10¹² Ω

Low input bias current: 25 pA (maximum)

High accuracy: ±0.2 mV ± 0.3% of reading

Root mean square conversion, signal crest factor up to 5

Wide supply voltage range: ±2.8 V, −3.2 V to ±16.5 V

Low power consumption: 25 μA (typical) standby current

Rated accuracy achieved without external adjustment

Technical specifications

Model: AD737JRZ

Type: RMS-to-DC converter

Package: SOIC-8 (5×4×1.5 mm)

Operating temperature: 0°C to 70°C (commercial grade)

Bandwidth: 10 kHz (20–200 mV input)

Input bias current: 25 pA (maximum)

Supply voltage range: ±2.5 V to ±16.5 V

Output polarity: Negative (AD736 is the positive output version)

Compliance standards: RoHS, lead-free
