The MSPM0G3107SDGS28R microcontroller adopts the enhanced Arm Cortex-M0+ 32-bit core platform, and the maximum operating frequency can reach 80MHz. This MCU offers high-performance analog peripheral integration, supports an operating temperature range of -40°C to 125°C, and operates under a power supply voltage of 1.62V to 3.6V.

The MSPM0G3107SDGS28R device offers an embedded flash program memory with an internal error correction code (ECC) of up to 128KB, as well as an SRAM with ECC and hardware parity options of up to 32KB. Its technical parameters include:

Core processor: ARM® Cortex®-M0+

Kernel specification: 32- bits

Speed: 80MHz

Connection capabilities: CANbus, I2C, SMBus, SPI, UART/USART

Peripherals: AES, Power Failure detection/reset, DMA, POR, PWM, TRNG, WDT

I/O number: 24

Program storage capacity: 128KB (128K x 8)

Program memory type: Flash memory

EEPROM capacity: -

RAM size: 32K x 8

Voltage-supply (Vcc/Vdd) : 1.62V to 3.6V

Data converter: A/D 11x12b SAR

Oscillator types: external, internal

Operating temperature: -40°C to 125°C (TA)

Installation type: Surface mount type

Supplier device packaging: 28-VSSOP

Application scenarios

The MSPM0G3107SDGS28R is suitable for applications that require high performance analog capabilities and low power consumption, such as industrial control, automotive electronics, smart home, wearable devices, etc. ‌.
