STM32F103VEH6 incorporates the high-performance ARM® Cortex®-M3 32-bit RISC core operating at a 72 MHz frequency, high-speed embedded memories (Flash memory up to 512 Kbytes and SRAM up to 64 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses. All devices offer three 12-bit ADCs, four general-purpose 16-bit timers plus two PWM timers, as well as standard and advanced communication interfaces: up to two I2Cs, three SPIs, two I2Ss, one SDIO, five USARTs, an USB and a CAN.

STM32F103VEH6 high-density performance line family operates in the –40 to +105 °C temperature range, from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving mode allows the design of low-power applications.

Specifications Of STM32F103VEH6

Core: ARM Cortex M3

Program Memory Size: 512 kB

Data Bus Width: 32 bit

ADC Resolution: 12 bit

Maximum Clock Frequency: 72 MHz

Number of I/Os: 80 I/O

Data RAM Size: 64 kB

Supply Voltage - Min: 2 V

Supply Voltage - Max: 3.6 V

Minimum Operating Temperature: - 40 C

Maximum Operating Temperature: + 85 C

Height: 1.09 mm

Interface Type: CAN, I2C, SPI, USART, USB

Length: 10 mm

Moisture Sensitive: Yes

Number of ADC Channels: 16 Channel

Number of Timers/Counters: 8 Timer

Width: 10 mm

Unit Weight: 343 mg
