The CSD95492QVM NexFET™ power stage is a highly optimised design for synchronous buck converters in high-power, high-power-density applications. This product integrates a driver IC and power MOSFET to enhance power stage switching functionality. This combination delivers high current, high efficiency, and high-speed switching capabilities in a 4mm × 5mm package. It also integrates accurate current sensing and temperature sensing functions to simplify system design and improve accuracy. Additionally, the PCB package has been optimised to help reduce design time and simplify overall system design.

CSD95492QVM Features

• 20A continuous operating current

• System efficiency exceeds 94% at 12A current

• High operating frequency (up to 1.25MHz)

• Diode emulation functionality

• Temperature-compensated bidirectional current sensing

• Analogue temperature output

• Fault monitoring

• Compatible with 3.3V and 5V pulse width modulation (PWM) signals

• Three-state PWM input

• Integrated bootstrap switch

• Optimised dead time for breakdown protection

• High-density 4mm × 5mm VSON package

• Ultra-low inductance package

• System-optimised PCB package

• RoHS compliant – lead-free pin plating

• Halogen-free

CSD95492QVM Applications

• Multi-phase synchronous buck converter

– High-frequency applications

– High current, low duty cycle applications

• Point-of-load (POL) DC/DC converters

• Memory and graphics cards

• Desktop and server VR12.x/VR13.x VRM synchronous buck converters
