The SN65HVD232DR is a 3.3V CAN bus transceiver introduced by Texas Instruments, compliant with the ISO 11898-2 high-speed CAN physical layer standard, and suitable for applications requiring reliable CAN communication, such as industrial automation, automotive electronics, and building automation. This device supports a maximum data rate of 1Mbps and features multiple protection functions to ensure stable operation in harsh environments.

SN65HVD232DR Features

• Powered by a single 3.3V supply

• Compliant with the ISO 11898-2 standard

• Low-power alternative to the PCA82C250 package

• Bus pin electrostatic discharge (ESD) protection exceeding ±16kV human body model (HBM)

• High input impedance, allowing up to 120 nodes to be connected on a single bus

• Adjustable driver transition time to improve radiation performance

– SN65HVD230 and SN65HVD231

• SN65HVD230: Low current standby mode

– 370μA (typical)

• SN65HVD231: Ultra-low current sleep mode

– 40nA (typical)

• Designed for data rates up to 1Mbps (1)

• Thermal shutdown protection

• Open-circuit fault-safe design

• Glitch-free power-on and power-off protection for hot-swap applications

SN65HVD232DR Key Parameters

Input voltage range: 3V to 3.6V

Data rate: Up to 1Mbps

ESD protection: ±16kV (HBM)

Common-mode voltage range: -2V to +7V

Package: SOIC-8

Operating temperature: -40°C to +85°C

Quiescent current: 10mA (typical)

Driver/receiver count: 1/1

SN65HVD232DR Applications

• Industrial automation, control, sensor, and drive systems

• Motor and robot control

• Building and temperature control (HVAC)

• Telecommunications and base station control and status

• Controller Area Network (CAN) bus standards, such as CANopen, DeviceNet, and CAN Kingdom
