The TVP5160PNP device is a high-quality digital video decoder that converts and decodes all common baseband analogue video formats into digital component video. The TVP5160PNP decoder supports analogue-to-digital conversion of component YPbPr and RGB (SCART) signals, as well as analogue-to-digital conversion and decoding of NTSC, PAL, and SECAM composite video and S-Video signals, converting them into component YCbCr format. Additionally, component progressive scan signals can also be digitally processed. The chip integrates two 11-bit, 60 MSPS analogue-to-digital converters (ADCs). Before each ADC, each analogue channel includes an analogue circuit that clamps the input signal to a reference voltage and applies programmable gain and offset. A total of 12 video input terminals can be configured, supporting combinations of YPbPr, RGB, CVBS, and S-Video video inputs.

TVP5160PNP Core Features

Supports multiple video input formats:

Composite video (CVBS)

S-Video (Y/C separated signals)

Component video (YPbPr, RGB/SCART)

Dual-channel 11-bit 60MSPS ADC, providing high-precision analogue-to-digital conversion.

Advanced 3D Y/C separation technology, reducing colour crosstalk (Cross-Luma/Cross-Chroma).

Supports ITU-R BT.601/BT.656 digital video output standards, compatible with mainstream video processors.

Macrovision™ copy protection detection (supports Types 1/2/3), suitable for copyright protection applications.

TVP5160PNP Key Features

High-precision ADC: 2 x 11-bit 60MSPS ADCs, supporting programmable gain and clamping control.

Multi-standard support:

NTSC (J, M, 4.43)

PAL (B, D, G, H, I, M, N, Nc, 60)

SECAM (B, D, G, K, K1, L).

3D noise reduction (3DNR) and time base correction (TBC) to enhance stability for weak signals and VCR recordings.

I²C host interface, programmable adjustment of brightness, contrast, chrominance, saturation, and other parameters.

Low-power design:

Analogue supply voltage: 1.65V to 1.95V

Digital supply voltage: 3.0V to 3.6V

VBI (vertical blanking interval) data processing, supporting Closed Caption (CC), Teletext, and other data extraction.

TVP5160PNP Application Areas

Digital TV

LCD TV/Monitor

DVD-R

PVR

PC Video Card

Video Capture/Video Editing

Video Conferencing
