The MLX90615SSG-DAA-000-TU is an infrared thermometer designed for non-contact temperature measurement. The infrared-sensitive thermopile detection chip and signal processing chip are both integrated into the same TO-46 can-type package. Thanks to its low-noise amplifier, 16-bit ADC, and powerful DSP unit, this thermometer achieves high accuracy and high resolution. The thermometer is factory-calibrated and features an interface compatible with the digital SMBus. The reading resolution is 0.02°C.

Model: MLX90615SSG-DAA-000-TU

Type: Digital Infrared (IR) Temperature Sensor

Brand: Melexis

Package: TO-46-4 Metal Can (Through-Hole Mounting)

Operating Temperature: -20°C to +85°C (local), -40°C to +115°C (remote infrared detection)

Key Features — MLX90615SSG-DAA-000-TU

High-Precision Temperature Measurement:

Resolution: 15 bits (0.02°C steps)

Accuracy: ±0.5°C (0°C to 60°C), ±3°C (60°C to 115°C)

Wide voltage supply: 2.6V to 3.6V (low-power design, static current 1.5mA)

Digital output interface: Supports PWM and SMBus (2-Wire), enabling direct reading by a microcontroller

Programmable features: configurable resolution, sleep mode (energy-saving design)

Automotive-grade certification: Compliant with AEC-Q100 standards, suitable for automotive electronics and industrial environments

Typical applications — MLX90615SSG-DAA-000-TU

Non-contact temperature measurement: Medical devices, industrial instruments, smart home applications (e.g., thermometers, appliance temperature control)

Automotive electronics: In-vehicle temperature monitoring, battery thermal management

Consumer electronics: Smart wearable devices, IoT sensor nodes
