The MLX90371GGO-BCC-300-RE utilises MELEXIS Triaxis® three-axis Hall technology, enabling a single chip to measure continuous rotation or linear displacement from 0° to 360°, with output configurable as either an analogue (proportional voltage) or PWM signal. The device is AEC-Q100 certified, meets the ISO 26262 ASIL-B functional safety standard, and is immune to stray magnetic fields, making it ideal for automotive and industrial applications requiring high reliability.

Key Features — MLX90371GGO-BCC-300-RE

• Triaxis® three-axis Hall technology for non-contact absolute position detection

• Resistant to stray magnetic field interference, suitable for strong magnetic field environments in new energy vehicles

• 12-bit angle resolution, 10-bit thermal accuracy, linear error ±1°

• Programmable transmission characteristics (4/8 points or 16/32 segments)

• Output mode: analogue proportional voltage 0–5 V or 12-bit PWM

• 48-bit unique ID for traceability and anti-counterfeiting

• Operating temperature –40 °C to +160 °C

• Single power supply 4.5 V – 5.5 V, typical 10 mA current

• Pin-compatible with Gen1/Gen2 products, upgrade with zero modification

Specifications — MLX90371GGO-BCC-300-RE

Technology: Three-axis Hall effect

Measurement range:    0° – 360° continuous rotation / linear displacement

Output interface:    Analogue (Ratiometric) / PWM

Resolution:    12-bit

Linearity:    ±1°

Supply voltage:    4.5 V – 5.5 V

Supply current:    10 mA (Typical)

Operating Temperature:    –40 °C to +160 °C

Package:    16-TSSOP (4.4 mm) Gull-wing SMD

Typical Applications — MLX90371GGO-BCC-300-RE

• Automotive brake pedal / accelerator pedal position detection

• Throttle, EGR valve, steering wheel angle measurement

• Vehicle height, suspension displacement, EPS motor position feedback

• Industrial servo motors, robot joints, magnetic encoders

• Non-contact potentiometers, liquid level float sensors
