The TMS5702135DZWTQQ1 device is a high performance automotive grade family of microcontrollers for safety systems. This safety architecture includes:

- Dual-core CPU running in lock-step mode

- CPU and memory built-in self-test (BIST) logic

- ECC on Flash and data SRAM

- Parity check on peripheral memory

- Loop functions on peripheral I/O

The TMS5702135DZWTQQ1 device integrates an ARM Cortex-R4F floating-point CPU that delivers a highly efficient 1.66 DMIPS/MHz and has configurations that can run at up to 180 MHz to deliver up to 298 DMIPS. The device supports the word-invariant large end-order [BE32] format.

Product Attributes

Core Processor: ARM® Cortex®-R4F

Core specification: 16/32-bit

Speed: 180MHz

Connectivity: CANbus，EBI/EMI，FlexRay，I²C，LINbus，MibSPI，SCI，SPI，ART/USART

Peripherals: DMA, POR, PWM, WDT

Number of I/O: 120

Program memory capacity: 2MB (2M x 8)

Programme memory type: Flash

EEPROM Size: 64K x 8

RAM Size: 256K x 8

Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.6V

Data Converter: A/D 24x12b

Oscillator Type: External

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: 337-LFBGA

Supplier Device Package: 337-NFBGA (16x16)

Application Areas

- Braking systems (anti-lock braking systems and electronic stability control)

- Electric power steering

- Hybrid Electric Vehicle (HEV) and Electric Vehicle (EV) Reverser Systems

- Battery management systems

- Active driver assistance systems

- Space and Avionics

- Railway

- Off-road vehicles
