The HMC532LP4ETR is a GaAs InGaP heterojunction bipolar transistor (HBT) MMIC VCO with integrated resonator, negative resistance device, varactor, buffer amplifier. The VCO operates at frequencies from 7.1 to 7.9 GHz. Due to the single-chip structure of the oscillator, its phase noise performance is excellent under different temperature, shock and vibration conditions. The power output is +14 dBm (typical) with a + 3V single power supply and 85 mA power consumption. This voltage controlled oscillator is available in a pinless QFN 4x4 mm surface mount package.

HMC532LP4ETR Features

Pout: +14 dBm

Phase Noise:-103 dBc/Hz (100 KHz)

No external resonator required

Single power supply: + 3V (85 mA)

QFN Leadless SMT Package, 16 mm ²

HMC532LP4ETR Properties

Product category: VCO oscillator

Product Type: VCO

Tuned voltage range (Vt): 1 VDC to 13 VDC

Power (dBm): 14 dBm

Second harmonic:-14 dBc

Current rating: 100 mA

Phase Noise Type:-101 dBc/Hz

Push: 78 MHz/V

Series: HMC532

HMC532LP4ETR Application

VSAT radio

Point-to-point/multipoint radio

Test equipment and industrial controls

Military end use
