The ICM-20602 is a 6-axis MotionTracking device that combines a 3-axis gyroscope, 3-axis accelerometer, in a small 3 mm x 3 mm x 0.75 mm (16-pin LGA) package.

ICM-20602 includes on-chip 16-bit ADCs, programmable digital filters, an embedded temperature sensor, and programmable interrupts. The device features an operating voltage range down to 1.71V. Communication ports include I2 C and high speed SPI at 10 MHz.

Applications Of ICM-20602

• Smartphones and Tablets

• Wearable Sensors

• IoT Applications

• Motion-based game controllers

• 3D remote controls for Internet connected DTVs and set top boxes, 3D mice

Features Of ICM-20602

• 3-Axis Gyroscope with Programmable FSR of ±250 dps, ±500 dps, ±1000 dps, and ±2000 dps

• 3-Axis Accelerometer with Programmable FSR of ±2g, ±4g, ±8g, and ±16g

• User-programmable interrupts

• Wake-on-motion interrupt for low power operation of applications processor

• 1 KB FIFO buffer enables the applications processor to read the data in bursts

• On-Chip 16-bit ADCs and Programmable Filters

• Host interface: 10 MHz SPI or 400 kHz Fast Mode I2C

• Digital-output temperature sensor

• VDD operating range of 1.71V to 3.45V

• MEMS structure hermetically sealed and bonded at wafer level

• RoHS and Green compliant
