Service Telephone:86-755-83294757
Trade Name:Surge Stopper
Brand:ADI
Particular Year:25+
Package:FCQFN-23
Delivery Date:New and Original
Stock: 2000pcs
MAX17616AAFD offers highly versatile and programmable protection boundaries for systems against input voltage faults and output overcurrent faults. Input-voltage faults (with positive polarity) are protected up to +80V (without Reverse Current Protection)/+75V (with Reverse Current Protection), by an internal nFET featuring low ON-resistance (20mΩ typ). The devices feature a programmable undervoltage-lockout (UVLO) thresholds by using external voltage-dividers.
Features Of MAX17616AAFD
Robust Protection Reduces System Downtime
Wide Input Supply Range: +3V to +80V (without Reverse Current Protection)
Wide Input Supply Range: +3V to +75V (with Reverse Current Protection)
±3% Accurate Programmable Current Limit between 3A to 7A across Full Temperature Range
±4% Accurate Programmable Current Limit between 2A to 3A across Full Temperature Range
±7% Accurate Programmable Current Limit between 0.7A to 2A across Full Temperature Range
Input-Voltage Reverse-Polarity Protection (with External nFET)
Dual Stage Reverse Current Protection (with External nFET) with Fast 100ns Response Time
Low RON Internal nFET (20mΩ typ)
Output-Voltage Reverse-Polarity Tolerant
Loss of Ground Protection
200% Short Term Overload capability
Programmable Overvoltage Surge Protection (MAX17616A)
PMBus Interface
Real Time Operating Conditions Monitoring, Voltage and Current Readout
Fault Registry Access and Management
Device ON/OFF Control
Current Limit Mode Selection
Startup Inrush Current Limit Selection
Short Term Over Current Limit and Time Selection
Flexible Design to Maximize Reuse and Minimize Requalification
Adjustable UVLO and OVLO/OVFB Thresholds
±2% Accurate Bandwidth Current Monitoring Read-Out, IMON (3A to 7A, up to +85ºC)
Programmable Startup Inrush Current Limit
Programmable Current Limit Fault Response: Continuous, Autoretry, and Latch-off Modes
Logic Level Enable Input (EN)
Protected External n-type field effect transistor (nFET) Gate Drive
Power Good Output (PGOOD)
Programmable Output Under Voltage Sense (OUTUV)
Junction Temperature Monitoring (TJ)
Thermal Foldback Current Limit
Reduced Solution Footprint
4.5mm x 5.75mm, 23-Pin FCQFN package
Integrated nFET for Common-Use Protection Requirements
Applications Of MAX17616AAFD
Input Voltage and Output Overcurrent Protections
Loss of Ground Protection
Surge Protection
Model
Brand
Package
Quantity
Describe
ADI
TQFN-20
2000
5.5V to 60V, 6A Current-Limiter with OV, UV, Reverse Protection, and Power Limit
ADI
TQFN-20
2000
5.5V to 60V, 6A Current-Limiter with OV, UV, Reverse Protection, and Power Limit
TI
10-VFDFN
2000
40V, 1.8A Power and Current Limiting eFuse with IN to OUT Short Detection
