Trade Name:Power Factor Correction - PFC
Brand:TI
Particular Year:25+
Package:SOT-23-6
Delivery Date:New and Original
Stock: 6000pcs
The UCC28056CDBVR is a PFC controller. The controller can directly drive up to 300W of output power while ensuring low sinusoidal line input current distortion and near 1 power factor. The device includes burst mode operation to further improve light load performance, allowing systems to comply with challenging energy efficiency standards without having to turn off the PFC. The UCC28056CDBVR can drive PFC power stages up to 300W, ensuring low sinusoidal line input current distortion and near 1 power factor while keeping the PFC ‘always on’. always on’. When used with the LLC controller UCC28056CDBVR, the 6-pin device eliminates the need for an auxiliary flyback converter, which is often required in systems to achieve good standby performance, while achieving a power consumption of less than 80mW at 230Vac. The device also enables instant-on while minimising the number of external components.
Features of the UCC28056CDBVR
Low input current distortion and power factor values near 1 with load reduction to 10%
Complies with IEC1000-3-2 requirements
Ultra-low no-load input power (25mW at 115Vac, 40mW at 230Vac)
Provides excellent efficiency over the load range
Achieves standby power consumption of less than 60mW at 115Vac and less than 80mW at 230Vac in PFC+LLC systems
Complies with green power standards without disabling PFC
EuP Lot 6 Level 2, CoC Ver. 5 Level 2, ENERGY STAR Ver. 6.1 for computers, DOE Level VI
Ultra-low audible noise output
Intermittent mode with soft in and soft out cycles
Enhanced EA for fast response to load steps without reducing input current distortion
No need for a second winding on the boost inductor to achieve valley synchronous turn-on
User-adjustable valley delay
Low start-up current consumption (<46 µA)
Wide VCC range of 8.5V to 34V
Cycle-by-cycle current limit
Second independent output voltage protection
Integrated over-temperature protection
Create custom designs using the UCC28056 device and WEBENCH® Power Designer
UCC28056CDBVR Applications
Desktop PCs/Digital TVs
Gaming/Set-Top Box/AC Adapter Front-End
LED drivers and lamps
Entry-level servers and web servers
