The IPL65R165CFD is a 650V CoolMOS™ CFD2 family of power transistors designed with Superjunction technology for fast switching and low loss characteristics. Suitable for high-voltage power applications, they offer excellent efficiency and reliability.

IPL65R165CFD Product Features

High voltage design: Supports 650V drain-source voltage (Vds).

Low on-resistance: Maximum on-resistance is 165mΩ (@10V, 9.3A).

Fast switching: Fast switching capability reduces switching losses.

Built-in fast body diode: Provides low reverse recovery charge (Qrr) to reduce losses during switching.

Low package size: 8.1x8.1mm in PG-VSON-4 package for space-constrained applications.

High power density: Supports power dissipation up to 195W.

Wide operating temperature range: Operating temperature range of -40°C to +150°C.

IPL65R165CFD Product Benefits

Low-loss design: Significantly reduced switching and conduction losses due to low on-resistance and fast body diodes.

High reliability: excellent EMI immunity and high voltage withstand capability.

Easy to design: Simplified circuit design for a wide range of high-voltage applications.

Cost Effective: Provides lower losses and higher efficiency than traditional 600V CFD technology.

IPL65R165CFD Potential Applications

The 650VCoolMOS™CFD2 is particularly well suited for resonant switching stages such as PCSilverbox, LCDTV, lighting, servers and telecoms.
