The NCP81109CMNTXG is a DC-DC switch controller in a 48-QFN (6x6mm) package for high-performance power management applications such as computing devices, servers, and embedded systems. The chip supports single-phase buck conversion and provides high efficiency and high accuracy voltage regulation for core power supply scenarios such as CPUs, GPUs, FPGAs, etc. The NCP81109CMNTXG is a DC-DC switching controller in a 48-QFN (6x6mm) package.

NCP81109CMNTXG Product Features

High efficiency: Integrated MOSFETs provide up to 95% conversion efficiency.

Wide input voltage range: Supports input voltages from 4.5V to 16V.

High output current: Supports up to 20A output current.

SVID Support: Supports Intel SVID (System Voltage Identification) interface for easy dynamic voltage regulation.

Compact package: 48-pin QFN package saves space.

Low-power design: Built-in low-power mode for energy-saving applications.

NCP81109CMNTXG Specifications

Product Category: Switch Controller

Topology: Buck

Number of Outputs: 1 Output

Switching frequency: 500 kHz to 1.2 MHz

Output voltage: 0 V to 2.3 V

Output current: 14 A

Minimum operating temperature: - 10 C

Maximum operating temperature: + 100 C
