The AD9941BSTZ is a complete analog signal processor for imaging applications that require no correlation double sampling (CDS). It is also suitable for processing the output signals of the AD9940 CDS front-end products. The device has a 56 MHz, single-channel architecture and is designed to sample and condition the output of CMOS imagers and CCD arrays with built-in CDS. The AD9941 signal chain consists of a differential input sample-hold amplifier (SHA), a digitally controlled variable gain amplifier (VGA), a black level clamp, and a 14-bit ADC.

Applications

Digital cameras using CMOS imagers

Professional HD TV camera

Professional/high-end digital camera

Broadcast camera

Features

Differential sensor input, input range is 1 V p-p

0 dB/6 dB Variable Gain Amplifier (VGA)

Low noise optical black clamp circuit

14-bit, 56 MSPS analog-to-Digital Converter (ADC)

No code loss is guaranteed

Three wire serial digital interface

3 V single power supply

Low power CMOS: 145mW (3.0V, 56MHz)

48-pin LQFP package
