Marvell® Alaska® 88E1510-A0-NNB2I000 Gigabit Ethernet (GbE) transceiver are physical layer devices each containing a single Gigabit Ethernet transceiver. The transceivers implement the Ethernet physical layer portion of the 1000BASE-T, 100BASETX, and 10BASE-T standards.

In addition to supporting Energy Efficient Ethernet (EEE) on the new generation of enabled MACs, these products are also capable of implementing EEE with legacy or non-EEE devices by incorporating EEE buffering. The devices also integrate MDI interface termination resistors into the PHY. This resistor integration simplifies board layout and reduces board cost by reducing the number of external components. The new Marvell calibrated resistor scheme will achieve and exceed the accuracy requirements of the IEEE 802.3 return loss specifications.

The Alaska family of transceiver products provides the ideal solution for rapid development and deployment of gigabit standalone and switching systems for the Enterprise, embedded, consumer, and Metro/service provider market segments.

Features

Four RGMII timing modes including integrated delays

Supports EEE (IEEE 802.3az)

Implements EEE with legacy or non-EEE MAC

Synchronous Ethernet

IEEE 1588v2 support

Wake on LAN (WoL)

Integrated Switching Voltage Regulator

Advanced Virtual Cable Tester® (VCT™)

48-pin QFN 7 mm x 7 mm Green package

Target Applications

The Alaska 88E1510-A0-NNB2I000 transceivers deliver optimal physical layer interfacing and features for a broad range of applications within the Enterprise, embedded, consumer, and Metro/service provider market segments.
