The ADV7182 automatically detects standard analogue baseband video signals compatible with global NTSC, PAL and SECAM standards and converts them to a 4:2:2 component video data stream. The video data stream is compatible with the 8-bit ITU-R BT.656 interface standard.

The digital video output stream of the ADV7182 can be easily interfaced with a wide range of MPEG encoders, codecs, mobile video processors and ADI's digital video encoders such as the ADV7391. External HS, VS and FIELD signals provide timing references for LCD controllers and other video ASICs.

Benefits and features

4 video input channels with built-in on-chip anti-alias filters

5-wire adaptive comb filter and CTI/DNR video enhancement features

One 10-bit analogue-to-digital converter (ADC) with 4x oversampling for CVBS, 2x oversampling for Y/C mode and 2x oversampling for YPrPb (per channel)

Excellent common mode rejection

Support for CVBS (composite), Y/C (S-video) and YPrPb (component) video inputs

Supports full differential, pseudo-differential and single-ended CVBS video inputs

Supports global NTSC/PAL/SECAM colour demodulation

For more features, please refer to the datasheet

Adaptive Digital Line Length Tracking (ADLLT), signal processing and enhanced FIFO management to provide TBC functionality

Fast video switching capability

Integrated automatic gain control (AGC) function provides adaptive peak white mode

Common mode input range solutions up to 4 V

Applications

Automotive infotainment

DVRs supporting video security surveillance

Media players
