Commodity Model:ADL5961ACCZ

Trade Name:RF Front-End

Brand:ADI

Particular Year:24+

Package:LGA-26

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADL5961ACCZ
Package
LGA-26
Describe
9kHz to 26.5GHz, Integrated Vector Network Analyser (VNA) Front End, LGA-26

Product Description

ADL5961ACCZ: 9kHz to 26.5GHz, Integrated Vector Network Analyser (VNA) Front End, LGA-26


Model: ADL5961ACCZ

Package: LGA-26

Type: RF Front End - Vector Network Analyser (VNA) Front End


The ADL5961ACCZ is a broadband, compact vector network analyser (VNA) front-end consisting of a resistive bi-directional bridge, down-converting mixer, programmable IF amplifiers and filters, and a highly flexible local oscillator (LO) interface. The bridge has a directivity of greater than 14 dB up to 17 GHz, and the main transmission line from RFIN to RFOUT is broadband matched to 50 Ω, with a loss of only 1.1 dB at 9 kHz near DC, increasing to 1.8 dB at 26.5 GHz.


ADL5961ACCZ - Product Features:

Wideband integrated bidirectional bridge

- Original directivity: 35.6 dB at 1 GHz, 16.7 dB at 18 GHz

- Low insertion loss: 1.1 dB at 1 GHz, 2.0 dB at 18 GHz

- Return loss >12 dB typical

SPI configurable LO interface

- Divide by 2; multiply by 1, 2, or 4

- Offset LO interface can be driven at fRF = fLO

- Single-ended or differential drive

- SYNC function - synchronisation across multiple devices

High dynamic range wideband IF signal path

- SPI programmable IF bandwidth from 1 MHz to 100 MHz

- SPI-programmable IF gain in 6 dB steps

- Externally adjustable output common mode level

5-bit SPI readable temperature sensor

Low-power shutdown mode

3 mm × 4 mm, 26-lead LGA
