The ADIN1300BCPZ is a low-power, single-port, Gigabit Ethernet transceiver with low latency designed primarily for industrial Ethernet applications. This design integrates the Energy Efficient Ethernet (EEE) physical layer device (PHY) core along with all associated common analog circuits, input and output clock buffers, management interface and subsystem registers, and MAC interface and control logic to manage reset and clock control and pin configuration.

The ADIN1300 supports 150 meters of cable at gigabit speeds and 180 meters of cable when operating at 100 Mbps or 10 Mbps.

Product Specifications:

Type: Transceiver

Protocol: IEEE 802.3

Number of drivers/receivers: 4/4

Duplex: full, half

Data rate: 10Mbps, 100Mbps, 1Gbps

Voltage - power supply: 1.71V ~ 1.89V, 2.25V ~ 2.75V, 3.14V ~ 3.46V

Operating temperature: -40°C ~ 105°C (TA)

Mounting type: Surface mount type

Package/housing: 40-WFQFN bare pad, CSP

Supplier package: 40-LFCSP-WQ (6x6)

Basic product number: ADIN1300
