The 10157096-01221LF is a pin holder connector with a pitch of 1.00mm with 24 positions.

Basic parameters:

Connector type: Connector

Contact type: male pin

Pitch - Connection: 0.039" (1.00mm)

Number of needles: 24

Number of rows: 2

Row spacing - Matching: -

Number of pins loaded: All

Style: Board to cable/wire

Shield: With shielding - 4 walls

Mounting type: Surface mount type

End connection: welding

Fastening type: latch support

Contact length - Matching: -

Contact length - column: -

Overall contact length: -

Insulation height: 0.213" (5.40mm)

Contact shape: rectangle

Contact surface treatment - Fitting: gold plating

Contact surface treatment thickness - Connection: 15.0µin (0.38µm)

Contact surface treatment - Column: tin

Contact material: phosphor bronze

Insulating material: polyamide (PA4T), nylon 4T

Features: Pick and place, welding hold

Operating temperature: -20°C ~ 85°C

Intrusion prevention: -

Material flammability grade: UL94 V-0

Insulation color: natural

Rated current (ampere) : 1A

Rated voltage: 50VAC/DC

Joint stack height: -

Contact surface treatment thickness - column: 100.0µin (2.54µm)
