Trade Name:Rectangular Connector
Brand:Samtec
Particular Year:22+
Package:3POS
Delivery Date:New and Original
Stock: 2000pcs
TSM-103-01-L-SV-P-TR is a 3-pin single-row surface mount (SMD) pin header connector belonging to the TSM series, specifically designed for high-density PCB board-to-board or cable interconnections. This connector features a standard pitch of 0.100" (2.54mm) and is suitable for applications in industrial control, communication equipment, consumer electronics, and other fields, offering high reliability and low contact resistance.
Core Specifications
Model: TSM-103-01-L-SV-P-TR
Connector Type: Pin Header (Male Pins)
Number of Pins: 3
Number of Rows: 1
Pitch: 0.100" (2.54mm)
Mounting Method: Surface Mount (SMT)
Contact Material: Phosphor Bronze
Contact Plating: Gold Plating (Mating End: 10µin/0.25µm)
Insulation Material: Liquid Crystal Polymer (LCP), UL94 V-0 Flame Retardant Rating
Operating Temperature: -55°C to +125°C
Contact Engagement Length: 0.230" (5.84mm)
Insulation Height: 0.100" (2.54mm)
Termination Method: Solder
Functional Features
High-reliability contact: Gold-plated contacts (10 µin) ensure low contact resistance and oxidation resistance, suitable for high-frequency signal transmission.
Compact design: SMT mounting saves PCB space, suitable for high-density layouts.
Wide temperature range: -55°C to +125°C, suitable for harsh industrial environments.
Quick assembly: Supports pick-and-place automated production.
Typical applications
Industrial automation: PLC modules, sensor interfaces.
Communication equipment: Optical modules, base station control boards.
Consumer electronics: Smart home controllers, portable devices.
