The MINI-MSDM250 is an Amphenol miniature manual service disconnect (Mini MSD) plug designed specifically for the high-voltage battery systems of plug-in hybrid electric vehicles (PHEVs) and electric vehicles (EVs). This connector integrates a 250 A fast-acting fuse, featuring a two-stage lever unlock mechanism and an internal HVIL (High-Voltage Interlocking Circuit), enabling safe disconnection of high-voltage circuits under live conditions. It is specifically designed for new energy vehicles, energy storage cabinets, and high-voltage distribution units.

MINI-MSDM250 Key Parameters

• Electrical Performance

Rated Voltage: 690V AC

Rated Current: 250A (with fuse protection)

Withstand voltage test: Complies with industrial-grade electrical safety standards

• Mechanical Characteristics

Mounting method: Panel mount

Dimensions: 91 mm (width) × 73.5 mm (height)

Colour: Orange (industry-standard high-voltage connector colour)

• Environmental Adaptability

Operating temperature range: -40°C to +70°C

Protection rating: IP67 (dustproof and waterproof)

Complies with RoHS standards (environmentally compliant)

• Safety and Protection

High-voltage interlocking circuit (HVIL): Disconnects the HVIL circuit before disconnecting the high-voltage contacts

Two-stage lever design: Prevents accidental operation

Fuse protection: 250A fuse prevents overload damage 26.

MINI-MSDM250 Typical Applications

• Electric Vehicles (EV/PHEV)

High-voltage battery pack maintenance disconnection

On-board charger (OBC) safety protection

Motor controller maintenance

• Industrial Power Systems

Energy storage system maintenance switch

Photovoltaic inverter high-voltage isolation
