PL00X-301-10M10 is a high-voltage power connector in the Amphenol PowerLok™ series, specifically designed for high-voltage power transmission systems in electric vehicles (EV) and hybrid electric vehicles (HEV). This connector features a modular, high-density contact design and supports a rated voltage of 1000V, making it suitable for critical applications such as battery management systems (BMS), motor drives, and on-board chargers (OBC).

PL00X-301-10M10 Features

Rated Voltage: 1000V DC (compliant with EV high-voltage standards)

Rated current: 100A (specific current may vary depending on application environment)

Withstand voltage test: 5000V DC (compliant with high-voltage safety standards)

Operating temperature range: -40°C to +125°C (suitable for extreme environments)

Protection rating: IP67 (dustproof and waterproof)

Compliant with RoHS standards (environmentally compliant)

Contact Type: Female, Straight

Contact Plating: Gold-plated/Silver-plated (optional), ensuring low contact resistance

Mounting Method: Panel Mount or Harness Connection

Secondary Locking Design (prevents accidental loosening)

EMI/RFI Shielding (reduces electromagnetic interference)

PL00X-301-10M10 Specifications

Type:    RADSOK

Form Factor:    Female

Position Count:    1 Position

Current Rating:    300 A

Voltage Rating:    1 kVDC

Installation Style:    Panel Mount

Termination Type:    Busbar

Installation Angle:    Straight

IP Rating:    IP67, IP6K9K

Flammability Rating:    UL 94 V-0

Colour:    Orange

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

PL00X-301-10M10 Typical Applications

Electric Vehicles (EV/HEV)

High-Voltage Battery Pack Connections

Motor Controllers

On-Board Chargers

Industrial Power Transmission

Energy Storage Systems

Photovoltaic Inverters

Industrial Automation Equipment
