The MINI-MSDM350 is an Amphenol miniature manual service disconnect (Mini MSD) plug designed specifically for the high-voltage battery systems of plug-in hybrid electric vehicles (PHEVs) and electric vehicles (EVs). This connector is equipped with a 350A fuse, supports 690V AC high-voltage applications, and integrates a high-voltage interlocking circuit (HVIL) function to safely disconnect the high-voltage battery pack during maintenance, preventing the risk of short circuits.

MINI-MSDM350 Key Parameters

• High Voltage/Current Capability

Rated Voltage: 690V AC (compliant with high-voltage safety standards)

Rated Current: 350A (with fuse protection)

Withstand Voltage Test: Compliant with industrial-grade electrical safety requirements

• Industrial-Grade Reliability

Operating Temperature Range: -40°C to +70°C (suitable for extreme environments)

Protection rating: IP67 (dustproof and waterproof)

Compliant with RoHS standards (environmentally compliant)

• Safety and Protection

High-voltage interlock circuit (HVIL): Disconnects the HVIL circuit before disconnecting high-voltage contacts to ensure operational safety

Two-stage lever design: Prevents accidental operation and enhances safety

Fuse protection: 350A fuse prevents overload damage

• Mechanical and Electrical Design

Mounting method: Panel mount (Panel Mount)

Color Coding: Orange (industry standard color for high-voltage connectors)

Dimensions: 91mm (Width) × 73.5mm (Height)

MINI-MSDM350 Typical Applications

• Main Positive/Main Negative MSD for Pure Electric Vehicles/PHEV Battery Packs

• Maintenance Breakpoints for Energy Storage Cabinets, Electric Buses, and Heavy-Duty Truck High-Voltage Busbars

• Safety Isolation for 800V Fast Charging Systems
