Trade Name:Silicon Carbide (SiC) MOSFET
Brand:Qorvo
Particular Year:24+
Package:D2PAK-3
Delivery Date:New and original
Stock: 3000pcs
The UJ3C065080B3 is a 650 V, 80 mohm SiC FET in a D2PAK-3L package, ideal for switching inductive loads and any application requiring standard gate drive.
Specifications
Technology: SiC
Installation style: SMD/SMT
Package/Box: D2PAK-3 (TO-263-3)
Transistor polarity: N-Channel
Number of channels: 1 Channel
Vds- drain-source breakdown voltage: 650 V
Id- Continuous drain current: 25 A
Rds On- drain-source on-resistance: 100 mOhms
Vgs - grid - source voltage: -25 V, + 25 V
Vgs TH-gate source threshold voltage: 4 V
Qg- Grid charge: 51 nC
Minimum operating temperature: -55 °C
Maximum operating temperature: + 175°C
Pd- Power dissipation: 115 W
Channel mode: Enhancement
Qualification: AEC-Q101
Brand name: SiC FET
Series: UJ3C
Configuration: Single
Descent time: 11 ns
Product type: MOSFET
Rise time: 13 ns
Typical shutdown delay: 59 ns
Typical connection delay: 18 ns
Unit weight: 3.082g
