The R9A06G037GNP is a high-performance NB-PLC(Narrowband Power line Communication) modem IC. It integrates a high-performance DSP core and an MCU core (Arm Cortex-M3). The DSP kernel mainly deals with the PLC PHY layer protocol, and the ARM kernel deals with the upper layer protocol. R9A06G037 supports a variety of PLC protocols, such as G3-PLC (CENELEC, ARIB and FCC), PRIME, etc.

Features

High performance DSP

Handles PLC PHY layers and other real-time operations

276MHz Maximum clock frequency

128KB instruction RAM and 128KB data RAM

Wittway's special instructions, read Solomon and others

Microcontroller (Arm Cortex-M3)

Handle PLC MAC layer and upper layer operation

138 MHz maximum clock frequency

512KB memory

AES128 Encryption and decryption hardware engine

CRC hardware engine

16KB of shared memory

Analog front-end circuit

Programmable and multiplexed universal Input/Output (GPIO) pins

UART (2ch), CSI (2ch), IIC, Serial ROM-IF(single/dual/quad-channel), PWM (2ch) and GPIO (16)

Integrated regulator :3.3V input and 1.1V output

Supply voltage :3.3V

Package size: 64-QFN, 9mm x 9mm, 0.5mm pitch

Operating temperature :-40 to +85℃
