Commodity Model:OPT4060DTSR

Trade Name:Ambient Light Sensor

Brand:TI

Particular Year:24+

Package:SOT-5X3-8

Delivery Date:New and Original

Stock: 4000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
OPT4060DTSR
Package
SOT-5X3-8
Describe
Ambient light sensor High-speed high-sensitivity RGBW colour sensor 8-SOT-5X3 -40 to 85

Product Description

The OPT4060DTSR is a single-chip, high-resolution colour sensor capable of measuring four channels, each with a specifically designed spectral response. Three of the four channels have a peak spectral response at red, green and blue wavelengths and the fourth channel has a broadband spectral response. By measuring from these channels, important characteristics of the lighting environment can be extracted, such as (i) light intensity (lux) and (ii) colour.The OPT4060 is available in a small SOT-5X3 package.


Features

- High-precision, high-speed colour optical/digital conversion via high-speed I2C interface

- Four-channel sensing using precision optical filters:

- Three channels with peak response at red, green, and blue wavelengths and NIR suppression >99.99% (850nm).

- Clear, wide bandwidth channels

- High resolution RGB colour measurement

- Semi-logarithmic output with seven binary logarithmic full-scale illuminance ranges, with highly linear response in each range

- Built-in automatic full-scale illuminance range selection logic switches measurement ranges based on input light conditions, with good gain matching between ranges

- 26-bit effective dynamic range from 2.15mlux to 144klux

- 12 configurable transition times from 600µs to 800ms per channel for a wide range of high speed and high accuracy applications

- External pin interrupts for hardware synchronised triggers and interrupts

- Low operating current: 24μA

- Ultra-low standby power consumption: 2μA

- Operating temperature range: -40°C to +85°C

- Wide supply range: 1.6V to 3.6V

- 5.5V voltage-tolerant I/O

- Selectable I2C address

- Small form factor:

- 2.1mm × 1.9mm × 0.6mm SOT-5X3 package


Applications

- Display brightness and colour adjustment

- Camera image correction

- Automatic white balance

- Building automation and control

- Lighting control systems
