ADL6316ACCZ is a transmit variable gain amplifier (VGA) that provides an interface from radio frequency digital-to-analog converters (RF DACs), transceivers, and systems on a chip (SoC) to power amplifiers.

Features

Transmit VGA for RF DAC, transceiver, and SoC to power amplifier interface

RF output frequency range: 500 MHz to 1000 MHz

Internal balun with bias tee to supply RF DAC outputs

Integrated VVA attenuation range with on-chip DAC: 20.5 dB

2-stage high linearity amplifiers

RF DSA attenuation range: 14 dB with 0.45 dB step resolution

50 Ω differential inputs and 50 Ω single-ended output

Fully programmable via a 4-wire SPI

Single 5 V supply

38-terminal, 10.5 mm × 5.5 mm LGA

APPLICATIONS

2G/3G/4G/long-term evolution (LTE) in FDD/TDD broadband communication systems
