The SCTWA40N12G24AG Silicon Carbide power MOSFET device features ST's advanced and innovative second-generation SiC MOSFET technology. The device features very low on-resistance per unit area and excellent switching performance. The switching loss varies almost independently of the junction temperature.

Product Characteristics

Transistor Type: N-Channel

Technology: MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss): 1200 В

Current at 25°C - Continuous Drain (Id): 33A (Tc)

Supply Voltage (Max Rds On, Min Rds On): 18 Ω: 18 В

Switching Resistance (Max) at Different Id, Vgs: 105 mOhm @ 20A, 18V

Vgs(th) at different Id (max): 5V @ 1mA

Gate charge (Qg) at different Vgs (max): 63 nK @ 18V

Maximum voltage: +22V, -10V

Input capacitance (Ciss) at different Vds (max): 1230 pF @ 800 V

Power Dissipation (Max): 290 W (Tc): 290 W (Tc).

Operating Temperature: -55°C ~ 200°C (TJ)

Grade: Automotive Grade

Certification: AEC-Q101

Mounting Type: Through Hole

Scope of Supply: TO-247-4

Package/Housing: TO-247-4

Applications

● Main inverter (electric traction)

● DC/DC converters for electric/hybrid vehicles

● On-board chargers (OBC)
