WNSCM160120W Silicon Carbide MOSFET is packaged in a 3-pin TO247 plastic package, specifically designed for high-frequency, high-efficiency systems.

 WNSCM160120W Features and Benefits

• Low on-resistance

• High switching speed

• 0V gate turn-off voltage, simplifying gate drive

• 100% UIS test passed

• Easy to parallel

• Controlled dV/dt, optimised electromagnetic interference (EMI)

• Reduced thermal requirements

• RoHS compliant

 WNSCM160120W Product Attributes

 FET Type: N-channel

Technology: MOSFET (Metal Oxide)

Drain-Source Voltage (Vdss): 1200 V

Current at 25°C - Continuous Drain (Id): 24A (Ta)

Drive Voltage (Maximum Rds On, Minimum Rds On): 20V

On-Resistance at Different Id and Vgs (Maximum): 196 mΩ @ 10A, 20V

Vgs(th) at different Id (maximum): 4.5 V @ 3 mA

Gate charge (Qg) at different Vgs (maximum): 35 nC @ 20 V

Vgs (maximum): +25 V, -10 V

Input capacitance (Ciss) at different Vds (maximum): 736 pF @ 1000 V

Power dissipation (maximum): 155W (Ta)

Operating temperature: -55°C to 175°C (TJ)

Mounting type: Through-hole

 WNSCM160120W Application areas

• Switch-mode power supplies

• Uninterruptible power supplies (UPS)

• Solar string inverters and solar optimisers

• Electric vehicle chargers

• Motor drivers
