DS560DF410AMNR is a four-channel multi-rate retimer with integrated signal conditioning. It extends the reach and robustness of long, lossy, crosstalkimpaired high-speed serial links.

Product Features

Quad-channel multi-protocol retimer with integrated signal conditioning

Low latency: <2000 ps (typical) at 26.5625 GBd

Integrated 2×2 crosspoint

Adjustable 4-tap TX FFE filter

On-chip eye opening monitor (EOM), PRBS generator, and PRBS checker for debug

Dual 1.8-V and 1.2-V supplies

–40°C to +85°C operating temperature range

7.65 mm × 7.65 mm BGA package with integrated AC coupling capacitors

Applications

Active electrical cables (AEC) (SFP, SFP-DD, QSFP, QSFP-DD, OSFP)

Front-port C2M attachment unit interface (AUI) jitter cleaning

Backplane (KR) and midplane C2C attachment unit interface (AUI) reach extension

Speed doubling (gearbox) with NRZ-to-PAM4 aggregation and de-aggregation
