Service Telephone:86-755-83294757
Trade Name:1EDI3033AS
Data Manual:1EDI3033AS.pdf
Brand:INFINEON
Particular Year:23+
Package:DSO-20
Delivery Date:New original
Stock: 1000pcs
The EiceDRIVER™ gate Driver 1EDI3033AS is a high voltage SiC-MOSFET driver designed for automotive motor drives above 5 kW. The device is based on Infineon's coreless transformer (CT) technology, which provides current insulation between low and high voltage domains. The device is designed to support 400 V, 600 V and 1200 V SiC-MOSFET technology.
Product attribute
Technology: Magnetic coupling
Number of channels: 1
Voltage - isolation: 5700Vrms
Common-mode transient immunity (min) : 150kV/µs
Propagation delay tpLH/tpHL (maximum) : 120ns, 120ns
Pulse width distortion (Max) : 20ns
Rise/fall time (typical) : 55ns, 45ns (Max)
Current - Output high, low: 12A, 12A
Current - Peak output: 12A
Voltage - Forward (Vf) (typical value) : -
Voltage output power supply: 3V ~ 5.5V
Class: Automobile class
Qualification: AEC-Q100
Operating temperature: -40°C ~ 150°C
Mounting type: Surface mount type
Package/housing: 20-BFSOP (0.295", 7.50mm wide)
Supplier device package: PG-DSO-20-91
Certification body: UL, VDE
Basic product number: 1EDI3033
Model
Brand
Package
Quantity
Describe
BROADCOM
16-SOIC
2000
Automotive 2.5A Gate-Drive Optocoupler with Integrated IGBT Desat Overcurrent Sensing
BROADCOM
16-SOIC
2000
Automotive 2.5A MOSFET Gate Drive Optocoupler with Integrated Desat Over Current Sensing
BROADCOM
16-SOIC
2000
Automotive 2.5A Gate Drive Optocoupler with Integrated Flyback Controller
ST
24-SOIC
1000
Gate Driver Channel 24-SO Automotive Galvanically Isolated Single Gate Driver
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
