The STM32WLE5CCU6 wireless remote MCU is based on the high-performance Arm® Cortex®-M4 32-bit RISC core architecture. It uses a 48-pin UFQFPN package, and its operating frequency is up to 48MHz. The Arm kernel implements a full set of DSP instructions and independent storage protection units (MPUs) to enhance application security. The MCU operates in a temperature range of -40°C to +105°C (+85°C with radio) and a supply voltage range of 1.8V to 3.6V. Design low power applications with a full set of power saving modes.

Product attribute

Series: STM32WL

Product type: ARM microcontroller-MCU

Core: ARM Cortex M4

Data bus width: 32 bit

Program memory size: 256 kB

Data RAM size: 64 kB

ADC resolution: 12 bit

Maximum clock frequency: 48 MHz

Number of input/output terminals: 43 I/ OS

Power supply voltage: 1.8V ~ 3.6V

Program memory type: Flash

Data Ram type: RAM

Interface type: I2C

Mounting type: surface mount type

Package/case: 48-UFQFPN (7x7)

Operating temperature: -40°C ~ 105°C

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
